| System parameters |
| Processor |
High-Performance Embedded SOC Processor |
| Operation system |
Embedded Linux Operation System |
| Network parameters |
| Ethernet |
10/100/1000 Mbps Self-Adaptive Ethernet |
| Network protocol |
TCP/IP, RTSP |
| Device interfaces |
| Network interface |
1 RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface |
| I/O input |
4 On-Off Input |
| I/O output |
2 On-Off Output, 2 Relay Output |
| RS-485 |
2 RS-485 Half-Duplex Port |
| USB |
1 USB Interface for Inserting U-Disk |
| General |
| Power supply |
12 VDC |
| Power consumption |
≤10 W |
| Working temperature |
-10° C to + 55° C (14° F to 131° F) |
| Working humidity |
10% to 90% |
| Certification |
FCC, IC, CE, C-TICK, ROHS, REACH, WEEE |
| Dimensions(L × W × H) |
436 mm × 215 mm × 67 mm (17.2" ×8.5" × 2.6") |
| Material |
Plastic |
