| Display parameters |
| Size |
10.1-inch |
| Operation method |
Capacitive touch screen |
| Type |
Colorful TFT screen |
| Video parameters |
| Lens |
Not supported. |
| FOV |
/ |
| Pixel |
/ |
| Audio parameters |
| Audio quality |
Noise suppression and echo cancellation |
| Network parameters |
| Communication protocol |
TCP/IP, SIP, RTSP |
| Wired network |
10/100 Mbps self-adaptive |
| Wi-Fi |
Wi-Fi 802.11 b/g/n |
| Bluetooth |
/ |
| Zigbee |
/ |
| Device interfaces |
| Network interface |
1 RJ-45 10/100 Mbps self-adaptive |
| Power interface |
1 |
| General |
| Button |
0 |
| Installation |
Surface mounting |
| Indicator |
0 |
| |
1118 g (with packaging)
660 g (without packaging)
|
| Protective level |
/ |
| Power supply method |
IEEE802.3af, standard PoE
12 VDC/1 A
|
| Working temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Working humidity |
10% to 90% |
| Dimensions |
254 mm × 166 mm × 22.55 mm (10.0" × 6.5" × 0.89") |
| Battery |
/ |
| Application environment |
Indoor |
| Power consumption |
≤ 6 W
|
