| Display parameters |
| Size |
/ |
| Operation method |
/ |
| Type |
/ |
| Video parameters |
| Supplement light |
IR supplement
|
| Lens |
Low Illumination 2 MP HD IR Camera |
| FOV |
Horizontal: 180° Vertical: 96° |
| Pixel |
Main stream : 1920 × 1080
Sub stream : 720 × 480
|
| Audio parameters |
| Audio quality |
Noise suppression and echo cancellation |
| Capacity |
| Sub door station capacity |
16 |
| Network parameters |
| Communication protocol |
TCP/IP, RTSP
|
| Wired network |
Support |
| Wi-Fi |
/ |
| Bluetooth |
/ |
| Device interfaces |
| Network interface |
1 |
| Exit button |
2 |
| Lock control |
2 |
| Door contact input |
2 |
| Power interface |
1 |
| General |
| Button |
/ |
| Installation |
Flush mounting, surface mounting |
| Indicator |
/ |
| |
Without package: 400 g
With package: 610 g
|
| Protective level |
IP65 |
| Working temperature |
-40° C to +55° C(-40° F to 131° F)
|
| Working humidity |
10% to 95%
|
| Dimensions |
98 mm × 99.8 mm × 43.9 mm (3.86" × 3.93" × 1.73") |
| Battery |
/ |
| Power supply |
24 VDC two-wire power supply (< 16 W)
or 12 VDC independent power supply (< 20 W)
|
| Application environment |
Outdoor |
| Power consumption |
≤10 W |
