| Display parameters |
| Size |
/ |
| Operation method |
Physical button |
| Type |
/ |
| Video parameters |
| Supplement light |
IR supplement
|
| Lens |
1 |
| FOV |
Horizontal 180°, vertical 96° |
| Pixel |
Main stream: 1920 × 1080, (720p configurable)͖; sub stream: 720 × 480 |
| Audio parameters |
| Audio quality |
Noise suppression and echo cancellation |
| Capacity |
| Sub door station capacity |
16 |
| Network parameters |
| Communication protocol |
TCP/IP, RTSP
|
| Wired network |
Two-wire transmission |
| Wi-Fi |
/ |
| Bluetooth |
/ |
| Device interfaces |
| Network interface |
0 |
| Exit button |
2 |
| Lock control |
2 |
| Door contact input |
2 |
| Power interface |
1 |
| General |
| Button |
1 |
| Installation |
Wall mounting |
| Indicator |
0 |
| |
/ |
| Protective level |
IP65 |
| Power supply method |
24 VDC two-wire power supply (< 16 W) or 12 VDC independent power supply (<
20 W)
|
| Working temperature |
-40 °C to 60 °C (-40 °F to 140 °F) |
| Working humidity |
10% to 95% |
| Dimensions |
98 mm × 99.8 mm × 43.9 mm (3.86" × 3.93\" × 1.73\")
|
| Battery |
/ |
| Application environment |
Outdoor |
| Power consumption |
24 VDC two-wire power supply (≤16 W) or 12 VDC independent power supply 20 W)
|
