| Video and Audio |
| IP Video Input | 4-ch Up to 12 MP resolution |
| HDMI Output | 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA Output | 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| CVBS Output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Incoming Bandwidth | 40 Mbps |
| Audio Output | 1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio | 1-ch, RCA (2.0 Vp-p, 1 k Ω) |
| Decoding |
| Decoding Format | H.265/H.265+/H.264/H.264+/MPEG4 |
| Decoding Capability | 2-ch@12 MP (20fps)/4-ch@8 MP (25fps)/8-ch@4 MP (30fps) |
| Synchronous playback | 4-ch |
| Recording Resolution | 12 MP/8 MP/6 MP/5 MP/4 MP/3MP/1080p/UXGA/720p /VGA/4CIF /DCIF/2CIF/CIF/QCIF |
| Network |
| Network Protocol | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
| Network Interface | 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| PoE |
| Interface | 4 RJ-45 10/100 Mbps self-adaptive Ethernet interfaces |
| Auxiliary Interface |
| SATA | 1 SATA interface |
| Capacity | Up to 8 TB capacity for each HDD |
| USB Interface | Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Alarm In/Out | 4/1 |
| General |
| Power Supply | 48 VDC, 1.8 A |
| Consumption | ≤ 15 W |
| Working Temperature | -10 to +55º C (+14 to +131º F) |
| Working Humidity | 10 to 90 % |
| Dimension (W × D × H) | 315 × 240 × 48 mm (12.4" × 9.4" × 1.9") |
| ≤ 1.18 Kg (2.6 lb) |
