| Hardware features |
| Serial port |
1 |
| Power switch |
1 |
| Alarm input |
1 Alarm, 1 Tamper |
| Alarm output |
1 PGM, AM/Output |
| 3.3v Output |
1, up to 10mA |
| Electrical characteristics |
| Power supply |
3 CR123 |
| Operation humidity |
10%~90% |
| Operation temperature |
–10℃ ~ 55℃ |
| Power consumption |
Quiescent current: 40.29 uA
Max current: 47.85mA
Voltage: 3 VDC
|
| Battery life span |
More than 5 years (report alarm 50 times per day) |
| Wireless transmission |
| RF frequency |
433MHz |
| RF method |
Two-way communication |
| RF modulation |
2GFSK |
| RF distance |
1300m |
| Display |
| Indicator |
3: Alarm/Tamper（Red）, Fault（Amber）, Signal Strength（Green/Red） |
| General |
| Installation method |
Put inside Wireless Ready Detector |
| Dimension(WxHxD) |
102*41*20mm |
| |
35g(Without Battery), 90g(With Battery) |
